Shim-pack MC Series
Nexera Mikros - Columns
Supporting Micro Flowrate Range Liquid Chromatography Mass Spectrometry System
Versatility
- Shim-pack MC C18 column with 1.9 μm UHPLC particle achieves excellent separation and peak shape.
- The high pressure rating of 70 MPa allows these columns to be compatible with a range of mobile phase flow rates from 1 to dozens of μL per minute.
- The metal coordinative adsorption is suppressed by deactivating the column parts in contact with the solution.
- Both small and large molecule compounds, such as peptides, can be analyzed.
- Excellent durability can be achieved even if the biological sample analysis.
Shim-pack Trap Columns
Trap Columns Wide Portfolio
- Shim-pack MCT C18/C8
70 MPa pressure limitation and a unique modification on the column inner surface protects against absorption of the molecule. - Shim-pack MCT LC18/LC8
A small-volume cartridge column with 40 MPa pressure limit. Useful in reducing the gradient delay for a low flow rate.
| Shim-pack MCT series | |||
|---|---|---|---|
| P/N | Bonded Phase | Diameter (mm) | Length (mm) |
| 228-59938-91 |
C18
|
0.3 |
35
|
| 228-59938-92 | 0.5 | ||
| 228-59939-91 |
C8
|
0.3 |
35
|
| 228-59939-92 | 0.5 | ||
| Shim-pack MCT L series (particle size 5 μm) | |||
|---|---|---|---|
| P/N | Bonded Phase | Diameter (mm) | Length (mm) |
| 227-32701-01 |
Trap column holder for Shim-pack MCT L
|
||
| 227-32702-01 | C18 | 0.3 |
5
|
| 227-32703-01 | C8 | 0.5 | |
